The picture above shows a 20 foot section of a “Finger Joint” expansion assembly produced by PT&P for the Howard Franklin Bridge from Tampa to St. Petersburg in Florida.

This section is assembled and ready for shipment. Note the galvanized finish on everything except the temporary shipping bars. Each assembly includes four sections having a total weight of 11,227 lb. The fingers on this bridge are tapered to minimize tire damage to vehicles.

Want to learn more about our other miscellaneous products. Browse through our past live webinars now!

The picture above show the replacement of a tank mounted on a truck by the Sweco Fab division of Piping Technology & Products, Inc. In this case the customer delivered the damaged tank to our site so measurements of the mounting could be obtained. The old tank (upper left) was damaged beyond repair when a vacuum was inadvertently created inside the tank.

Do you require a tank or vessel for an upcoming project? Let us price it for you today!

This damper was fabricated from a combination of 304 stainless steel and Inconel®. It is designed as a shut-off damper to control the flow of flue gas in an ammonia plant. The damper will be connected to a motor-driven control system by the linkage shown in the picture. The overall dimensions are 10′ x 6′ with a weight of 2,200 lb. It was painted with standard inorganic zinc primer and top coat per customer specifications. The damper went through visual inspection, dye-penetrant, and functional testing before being shipped to the customer. Refractory lining, utilized to withstand the high temperatures, will be added during installation.

Do you have an application that requires a damper? Get pricing today!

The picture above shows four bellmouth reducers which have just received the final coat of a special paint. These are components of the cooling water piping system designed for large, new petrochemical complex. The bell shape is a segment of an ellipse chosen to function as a vortex breaker during high velocity flow.

Need bellmouth reducers for an upcoming project? Let us price it for you today!

Pictured above are spectacle blinds. Piping Technology & Products, Inc. builds these for any pipe size up to 60”. A variety of metals can be used including carbon steels, stainless steels or exotic alloys depending on the pressure rating required and the environment where they must function.

Do you need any spectacle blinds for an upcoming project? Let us price it for you today!

Shown above is one of three neutralization tanks engineered and fabricated by Sweco Fab, Inc. This particular tank is being shipped to the paint contractor for painting and special interior coating.

These tanks are 12 feet in diameter, 39 feet 7 inches high, and have a storage capacity of 25,000 gallons. Special features requested by the client include clips welded on the interior for mounting of headers.

Do you require a tank or vessel for an upcoming project? Let us price it for you today!

The photograph above shows a surge protection vessel fabricated to ASME code specifications by Sweco Fab, Inc. This vessel was purchased by a major Houston E&C firm for export to an overseas project.

Do you require a tank or vessel for an upcoming project? Let us price it for you today!

The photograph above shows a launcher-receiver designed to be installed in a six inch pipe to launch and receive pipeline pigs. Pigs can be used for cleaning or for separation of two products in the same pipeline. This launcher-receiver was one of two built by the SWECO Fab, Inc. division of Piping Technology & Products, Inc. for a major Gulf Coast Refinery.

Would you like to learn more about our pig launcher and receivers? Visit our webinar archives today!

Pictured above is one of the six identical tanks Sweco Fab, Inc. supplied for the expansion of City of Houston’s Sims Bayou Waste Treatment Plant.

These carbon steel tanks are rubber lined and have a special paint outside. Each tank has 6,000 gallon capacity.

Do you require ASME pressure vessels or tanks? Let us price them for you today!

The picture above shows special components of today’s piping systems. At the top are two rings with machined surfaces required to help seal the system when operating at high pressures. Rings and spacers can be fabricated from a variety of metals including carbon steels, stainless steels, alloys such as Inconel®, Hastelloy or Titanium. The choice of materials depends on the temperatures and pressures the system is designed for. Holes can be drilled to produce bleed rings which relieve pressure slowly. The above picture shows orifice plates which are made from the same materials.
